Border-only breadcrumb shape using modern CSS

A few lines of code to create a border-only breadcrumb shape that you can easily adjust

Create a border-only breadcrumb shape using a few lines of code and modern CSS.

• No extra element
• Powered by clip-path & math functions
• Optimized with CSS variables

Border-only breadcrumb shape using CSS

.breadcrumb {
  --b: 5px;    /* the border thickness */
  --a: 40deg;  /* control the shape */
  --c: #64908A;

  line-height: 1.8; /* control the height  */
  padding-inline: calc(.5lh*tan(var(--a)) + var(--b)/cos(var(--a)));
  position: relative;
}
.breadcrumb:before {
  content:"";
  position: absolute;
  inset: 0;
  background: var(--c);
  clip-path: polygon(0 0,calc(100% - .5lh*tan(var(--a))) 0,100% 50%,calc(100% - .5lh*tan(var(--a))) 100%,0 100%,calc(.5lh*tan(var(--a))) 50%,0 0,calc(var(--b)*(tan(var(--a)) + 1/cos(var(--a)))) var(--b), calc(.5lh*tan(var(--a)) + var(--b)/cos(var(--a))) 50%,calc(var(--b)*(tan(var(--a)) + 1/cos(var(--a)))) calc(100% - var(--b)),calc(100% - .5lh*tan(var(--a)) - var(--b)*(1/cos(var(--a)) - tan(var(--a)))) calc(100% - var(--b)),calc(100% - var(--b)/cos(var(--a))) 50%,calc(100% - .5lh*tan(var(--a)) - var(--b)*(1/cos(var(--a)) - tan(var(--a)))) var(--b),calc(var(--b)*(tan(var(--a)) + cos(var(--a)))) var(--b))
}
.breadcrumb:first-child:before {
  clip-path: polygon(0 0,calc(100% - .5lh*tan(var(--a))) 0,100% 50%,calc(100% - .5lh*tan(var(--a))) 100%,0 100%,0 0,var(--b) var(--b),var(--b) calc(100% - var(--b)),calc(100% - .5lh*tan(var(--a)) - var(--b)*(1/cos(var(--a)) - tan(var(--a)))) calc(100% - var(--b)),calc(100% - var(--b)/cos(var(--a))) 50%,calc(100% - .5lh*tan(var(--a)) - var(--b)*(1/cos(var(--a)) - tan(var(--a)))) var(--b),var(--b) var(--b))
}
.breadcrumb:last-child:before {
  clip-path: polygon(0 0,100% 0,100% 50%,100% 100%,0 100%,calc(.5lh*tan(var(--a))) 50%,0 0,calc(var(--b)*(tan(var(--a)) + 1/cos(var(--a)))) var(--b), calc(.5lh*tan(var(--a)) + var(--b)/cos(var(--a))) 50%,calc(var(--b)*(tan(var(--a)) + 1/cos(var(--a)))) calc(100% - var(--b)),calc(100% - var(--b)) calc(100% - var(--b)),calc(100% - var(--b)) var(--b),calc(var(--b)*(tan(var(--a)) + cos(var(--a)))) var(--b))
}

See Border-only breadcrumb shape by t_afif on CodePen.
