A halftone is a pattern of dots that vary in size and spacing. It's a printing technique that you normally don't see, but blown up in size, is a cool aesthetic. This is a deep dive on how it can be done in CSS alone, starting quite simply!

About half a decade ago, I got an idea about how to create a halftone effect with pure CSS. My original idea (which Michelle Barkerwrote abouta couple of years ago) was a bit inefficient, but in the years that followed, I’ve managed to polish it and reduce it to a single <div>, no pseudos and just three CSS properties.

What’s a halftone effect?

If you don’t know what ahalftoneeffect is, a very basic pattern looks like this:

This is what we’ll be creating with a single <div> (no pseudo-elements) and only three CSS declarations. Afterwards, we’ll go through a bunch of variations and see some cooler-looking demos.

The 3 CSS Declarations

Thefirst declarationis abackground and it consists of two layers. One is thepattern- the dots in our most basic case. The other is themap- this decides where the dots are bigger and where they are smaller. In the most simple case, it’s a linear gradient. So what we have so far in terms of code looks like this:

background:
  radial-gradient(closest-side, #000, #fff) 0/ 1em 1em space,
  linear-gradient(90deg, #000, #fff);

We’ve made sure we have an integer number of dots along both axes by using thespacevalue forbackground-repeat.

Taken separately, the two layers look like this:

Before we move any further, let’s take a closer look at these gradients. Each of the two layers goes fromblack, which can also be written asrgb(0%, 0%, 0%)orhsl(0, 0%, 0%)towhite, which can also be written asrgb(100%, 100%, 100%)orhsl(0, 0%, 100%).

Dead in the middle we havegrey, which isrgb(50%, 50%, 50%)orhsl(0, 0%, 50%). This is the50%lightness grey or, in short, as we’ll be calling it from now on, the50%grey.

Note that in the case ofanygrey, wherever it may be situated in between black and white, the saturation (the ‘S’ in HSL) is always0%, while the hue (the ‘H’ in HSL) is irrelevant, so we just use0. The only value that changes is the lightness (the ‘L’ in HSL), which goes from0%forblackto100%forwhite.

Basically, going from0%to100%along the gradient line means going from0%to100%along the lightness axis of theHSL bicone (thebabydino).

HSL bicone slice showing the lightness axis<br/>(live demo (<VPIcon icon="fa-brands fa-codepen"/>)) — HSL bicone slice showing the lightness axis
(live demo (`thebabydino`))

So in general, anyp%grey can be written asrgb(p%, p%, p%)orhsl(0, 0%, p%).

This can be seen in the interactive demo below where you can drag the bar along the entire lightness range.

See lightness axis by thebabydino on CodePen.

Going back to ourbackgroundwith the pattern dots layer on top of thelinear-gradient()map layer, we cannot see the map layer because it’s fully covered by the pattern layer. So the next step is to blend these twobackgroundlayers using themultiplyblend mode.

This means thesecond declarationis:

background-blend-mode: multiply

This works on a per pixel, per channel basis. We consider each layer to be a grid of pixels, we take every pair of corresponding pixels from the two layers and, for each of the three RGB channels, we multiply the corresponding channel values.

So for each pair of pixels, the result of this blending operation is an RGB value where each channel value is the result of multiplying the corresponding channel values from the two layers.

\begin{align*} \text{R}&=\text{R}_{0}\cdot\text{R}_{1} \text{G}&=\text{G}_{0}\cdot\text{G}_{1} \text{B}&=\text{B}_{0}\cdot\text{G}_{1} \end{align*}

Note that what we’re multiplying is the decimal representation of percentage RGB values - that is, numbers in the[0, 1]interval. And when multiplying values in this interval, the result is always smaller or equal to the smallest of the two values multiplied.

In our case, both gradients go from black to white, all we have in between are greys, which have all three RGB channels equal. So if at some point, both pixels in the pair of corresponding ones from the two layers havergb(50%, 50%, 50%), then the result of themultiplyblend mode is.25 = .5·.5for each channel.

We can see that the result of themultiplyblend mode is alwaysat least as darkas the darker of the two pixels whose RGB values we multiply. This is because the two RGB values are in the[0, 1]interval and, as mentioned before, multiplying such values always gives us a result that’s at most as big as the smallest of the two numbers multiplied. The smaller the channel values are, the darker the grey they represent is.

After blending our pattern and map layers, we can see how overall, the pattern dots are now darker on the left where the map is closer toblack.

Below, you can see two scaled up dots from different points along the gradient line of the map. The second dot is further to the right (lighter) than the first one. The dark red circles mark the50%grey limit for each.

For the darker dot, the50%grey limit is a bigger circle than in the case of the lighter dot. Inside each dark red circle, we have greys darker than a50%one. Outside, we have greys lighter than a50%one. Keep this in mind for later.

The third andfinal declarationis afilterusing a largecontrast()value.

For those not familiar with howcontrast()works, it does one of two things, depending on whether its argument is subunitary or not.

If its argument is subunitary, then it pushes every channel value towards.5, the middle of the[0, 1]interval. A value of1means no change, while a value of0means the channel has been pushed all the way to.5.

This means thatcontrast(0)always gives us a50%grey, regardless of thefilterinput.

You can see this in the interactive demo below - regardless of whether we apply ourfilteron a plain solidbackgroundbox, opaque or semitransparent, a gradient or an image one, dragging the contrast down to0always turns it into a50%grey with the same alpha as the input.

See contrast() with subunitary value by thebabydino on CodePen.

Note thatcontrast(100%)is the same ascontrast(1),contrast(50%)is the same ascontrast(.5)and so on.

If the argument of thecontrast()function is greater than1however, then each channel value gets pushed towards either0or1, whichever is closer. A contrast large enough can push the channel values all the way to0or1.

See contrast() with superunitary value by thebabydino on CodePen.

If we have a large enough contrast, all channel values are either zeroed (0%) or maxed out (100%) meaning we can only get one of eight possible results.

8 possible RGB values where all channels are either zeroed or maxed out

Coming back to our halftone pattern, we use:

filter: contrast(16)

Here, all greys darker than a50%one (greyorrgb(50%, 50%, 50%)orhsl(0, 0%, 50%)) get pushed toblackand all the others towhite.

Now remember how the50%grey limit was a bigger circle if the dot was darker? That’s our limit for the contrast.

Inside that circle, we have greys darker than a50%one, so they get pushed toblackby large contrast vales. Outside it, the greys are lighter than a50%one, so they get pushed towhiteby large contrast values.

Since the darker the dot, the bigger the50%limit circle, this means the halftone dots in the darker area of the map are bigger.

So here’s the result we get after the third and final declaration:

We’re starting to get somewhere, but what we have so far is not ideal. And it makes sense we aren’t there yet.

Since the left half of the map is darker than a50%grey (the RGB channel values are below50%or.5in decimal representation of the percentage), blending any other layer with it using themultiplyblend mode gives us a result that’s at least as dark.

This means the result of blending across the entire left half is a grey darker than a50%one, so that large value contrast pushes everything in the left half toblack.

The fix for this is pretty straightforward: we don’t make our gradients go all the way from black to white, but rather from mid greys to white. Furthermore, for best results, the map at its darkest should be a little bit brighter than a50%grey, while the pattern can be a bit darker.

background:
  radial-gradient(closest-side, #777, #fff) 0/ 1em 1em space,
  linear-gradient(90deg, #888, #fff);

Much better!

See Pure CSS halftone pattern, 1 elem, 3 declarations by thebabydino on CodePen.

Now one thing to note here is that the contrast value needs to be enough to compensate for the blur radius of our dots. So if we increase the pattern size (thebackground-sizefor the pattern layer), then we also need to increase the contrast value accordingly.

Let’s say we increase thebackground-sizefrom1emto 9em.

The dot edges are now blurry, so we also increase the contrast value from16to let’s say80.

Unfortunately, this results in ugly edges.

A fix for this would be to then chain a slight blur and a contrast that’s enough to offset it. Generally, a contrast value that’s 2-3 times the blur value in pixels works pretty well.

filter: contrast(80) blur(2px) contrast(5)

Aneven better fixwould involve using a custom SVGfilter, but SVG filters are outside the scope of this article, so we’re not going there.

Variations

Now that we’ve gone through the basics, we can start making things more interesting in order to get a lot of cool results by varying at least one of the pattern or map layers.

background:
  var(--pattern, radial-gradient(closest-side, #777, #fff) 0/ 1em 1em space)),
  var(--map, linear-gradient(90deg, #888, #fff));
  background-blend-mode: multiply;
  filter: contrast(16)

Pattern variations

In this part, we’re keeping the map gradient unchanged and keeping the same hex values for the pattern gradients, though the pattern gradients themselves change. Depending on the pattern, we might also adjust the contrast.

If you search for halftone patterns online, you’ll see that most of them don’t show a straight grid like we had above. So let’s fix that with a pattern made up of two layers.

--dot: radial-gradient(closest-side, #777, #fff calc(100%/sqrt(2)));
--pattern: var(--dot) 0 0/ 2em 2em, var(--dot) 1em 1em/ 2em 2em

In practice, I’d probably use a variable instead of2emand compute the offsets for the second layer of dots to be half of that.

Also, since we’ve increased the size of the dots, we’ve also bumped up the contrast value from16to24.

Another option would be to use arepeating-radial-gradient().

--pattern: repeating-radial-gradient(circle, #777, #fff, #777 1em)

Something like this can even be animated or made interactive. We can place these halftone ripplesat var(--x) var(--y)and change these custom properties onmousemove.

See Cursor following halftone rings (move fast) by thebabydino on CodePen.

We don’t have to limit ourselves to radial gradients. Linear ones work just as well. We can use arepeating-linear-gradient(), for example:

--pattern: repeating-linear-gradient(#777, #fff, #777 1em)

We can also animate the gradient angle (like in the demo below on hover) or make it change as we move the cursor over the pattern.

See Animated halftone lines (hover) by thebabydino on CodePen.

We can also restrict thebackground-sizeof alinear-gradient():

--pattern: linear-gradient(45deg, #fff, #777) 0 / 1em 1em

Just like for the first dots pattern variation, here we’ve also bumped up the contrast.

We can also add one extra stop:

--pattern: linear-gradient(45deg, #fff, #777, #fff) 0 / 1em 1em

For both of the previous ones, the gradient angle can also be animated. This can be seen on hovering the panels in the demo below.

See Halftone triangles/ fragments (hover) by thebabydino on CodePen.

We can also play with conic gradients here. A simple repeating one produces rays that are thicker on the left than on the right.

--pattern: repeating-conic-gradient(#777, #fff, #777 2.5%)

Without anyfilteradjustment however, the edges of these rays look bad, and so does the middle.

Using the tiny blur plus a contrast value that’s 2-3 times the blur tactic fixes the ray edges:

smooth ray edges, but faded pattern edges

… but the pattern’s edges are now faded! We have two possible fixes here.

The first would be to remove thefilterfrom the element itself and apply it on another element stacked on top of it as abackdrop-filter.

See smooth rays without fading edges #1 by thebabydino on CodePen.

The second would be to make the element extend outwards a bit using a negativemarginand then clip its edges by the same amount usinginset().

See smooth rays without fading edges #2 by thebabydino on CodePen.

Things get a lot more fun if we limit thebackground-sizeof such aconic-gradient()pattern and then play with the start angle--aand the end percentage--p.

--pattern:
  repeating-conic-gradient(var(--a),
    #fff, #777, #fff var(--p)) 0/ 3em 3em

See conic-gradient halftone pattern variations by thebabydino on CodePen.

Map variations

In this part, we’re keeping the pattern constant and trying out different maps.

Ourlinear-gradient()map doesn’t necessarily need to go along thexaxis - it can of course have a variable angle:

--map: linear-gradient(var(--a), #888, #fff)

The demo below shows this angle being animated on hover:

See Animated halftone direction (hover) by thebabydino on CodePen.

We can also add an extra stop:

--map: linear-gradient(var(--a), #fff, #888, #fff)

Again, hovering the demo below animates the map direction.

See Animated halftone direction #2 (hover) by thebabydino on CodePen.

We can also make our gradient a repeating one:

--map:
  repeating-linear-gradient(var(--a), #fff, #888, #fff var(--p))

See Animated halftone direction #3 (hover) by thebabydino on CodePen.

Or we can switch to aradial-gradient():

--map:
  radial-gradient(circle at var(--x) var(--y), #888, #fff)

In the demo below, the radial gradient’s position follows the cursor:

See Animated halftone position (hover) by thebabydino on CodePen.

The radial gradient can be a repeating one too:

--map:
  repeating-radial-gradient(circle at var(--x) var(--y),
    #fff, #888, #fff var(--p))

See Animated halftone position #2 by thebabydino on CodePen.

Same thing goes for conic gradients.

--map:
  conic-gradient(from var(--a) at var(--x) var(--y),
    #fff, #888, #fff)

See Animated halftone sweep (hover) by thebabydino on CodePen.

We can use a repeating one and control the number of repetitions as well.

--map:
  repeating-conic-gradient(from var(--a) at var(--x) var(--y),
    #fff, #888, #fff var(--p))

See Animated halftone rays (hover) by thebabydino on CodePen.

One thing that bugs me about some of the map variation demos, particularly about this last one, is the dot distortion. We can make it look less bad by sizing the element with the halftonebackgroundsuch that both its dimensions are multiples of the dot size and change the position in increments of the same dot size.

--d: 1em;
--pattern:
  radial-gradient(closest-side, #777, #fff)
    0/ var(--d) var(--d);
--map:
  repeating-conic-gradient(from var(--a)
    at round(var(--x), var(--d)) round(var(--y), var(--d)),
    #fff, #888, #fff var(--p));
width: round(down, 100vw, var(--d));
height: round(down, 100vh, var(--d));

But it’snot enough (thebabydino). In order for our dots to always be perfectly round, we need an SVGfiltersolution (thebabydino). However, that’s outside the scope of this article, so we’re not discussing it here.

Even more interestingly, our map can be an image too. Taking any random image as it is won’t work well.

using a random image as it is for the map doesn’t work well

We need to bring its saturation down to zero and, for this particular technique, we need to make sure the lightness of its pixels is pretty much in the[50%, 100%]interval.

Thefilter() (web-platform-tests/interop)functioncould help (thebabydino)here, but, sadly, foralmost a decade now, Safari has remained the only browser implementing it. We could make the pattern and the map layer each be a pseudo of an element, blend them together and apply the contrastfilteron the pseudo-elements’ parent. This way, the map pseudo could have afilterapplied on it too. However, here we’re looking for solutions that don’t involve extra elements or pseudo-elements.

Something we can do is make the map be the result of multiple blended background layers. Making thebackground-coloranygrey and blending it with the map image using theluminosityblend mode gives us a result that has the luminosity of the map image on top, the saturation of thebackground-colorbelow and, since this is a grey (its saturation is0%), the hue becomes irrelevant.

Note that luminosity isnot the same as lightness (thebabydino)(which is the ‘L’ in HSL), though in a lot of cases, they’re close enough.

--pattern:
  radial-gradient(closest-side, #777, #fff) 0/ 1em 1em space;
--map: url(my-image.jpg) 50%/ cover grey;
background: var(--pattern), var(--map);
background-blend-mode:
  multiply /* between pattern & map */,
  luminosity /* between map layers */;
filter: contrast(16)

We seem to be going in the right direction.

using a fully desaturated map obtained via blending

But it’s still not what we want, as this desaturated map is too dark, just like the firstblacktowhitemap gradient we tried.

We can brighten our map using thescreenblend mode. Think of this blend mode as being the same asmultiply, only with the ends of the lightness interval reversed.multiplyalways produces a result that’s at least as dark as the darkest of its two inputs,screenalways produces a result that’s at least as bright as the brightest of its two inputs.

In our case, if we usescreento blend the desaturated image we got at the previous step with a midway grey like#888, then the result is always at least as bright as#888. And it is#888only where we blend it with pure black pixels. Wherever we blend it with pixels brighter than pure black, the result is brighter than#888. So basically, we get a map that’s#888at its darkest, just like our base map gradient.

--pattern:
  radial-gradient(closest-side, #777, #fff) 0/ 1em 1em space;
--map:
  conic-gradient(#888 0 0),
  url(my-image.jpg) 50%/ cover
  grey;
background: var(--pattern), var(--map);
background-blend-mode:
  multiply /* between pattern & map */,
  screen /* between map layers */,
  luminosity /* between map layers */;
filter: contrast(16)

Much better!

using a fully desaturared and brightened map via blending<br/>(live demo (<VPIcon icon="fa-brands fa-codepen"/>)) — using a fully desaturared and brightened map via blending
(live demo (`thebabydino`))

Again, some of the dots aren’t fully round, but in order to get fully round dots, we’d need an SVGfilterand that’s a way too big of a topic to discuss here.

Palette variations

The simplest possible variation would be having white halftone dots on a black background. To do this, we can simply chaininvert(1)to ourfilter.

Or… we can do something else! We can use thescreenblend mode we’ve used before to brighten the image map. As mentioned, this works likemultiply, but with the ends of the lightness interval reversed. So let’s reverse them for both the pattern and the map.

background:
  var(--pattern,
    radial-gradient(closest-side, #888, #000) 0/ 1em 1em space),
  var(--map,
    linear-gradient(90deg, #777, #000));
background-blend-mode: screen;
filter: contrast(16)

inverted halftone dots pattern<br/>(live demo (<VPIcon icon="fa-brands fa-codepen"/>)) — inverted halftone dots pattern
(live demo (`thebabydino`))

But we’re not limited to just black and white.

Remember the part about how contrast works? Large contrast values push all pixels of thefilterinput to one of 8 possible RGB values. So far, ourfilterinput has been just greys, so they got pushed to either black or white. But we don’t necessarily need to have just greys there. We could tweak those values to either zero or max out a channel or two everywhere.

For example, if we max out one of the channels, then our black dots get that channel added to them. Maxing out the red channel gives us red dots, maxing out the blue channel gives us blue dots, maxing out both the red and blue channels gives us magenta dots.

Going the other way, if we zero one of the channels, then it gets subtracted out of the white background. Zeroing the blue channel gives us a yellow background (the red and green channels are still maxed out for the background and combined, they give yellow). Zeroing the red channel gives us a cyan background. Zeroing both the blue and green channels gives us a red background.

You can play with various scenarios in the interactive demo below:

See palette variations by thebabydino on CodePen.

We can of course also have more interesting palettes and we can even have halftone dots on top of image backgrounds using the pure CSSblending technique (thebabydino)I detailed ina talk on the topic (thebabydino)I used to give in 2020 or by usingSVG (thebabydino)filters (thebabydino). Both of these approaches however require more than just one element with no pseudos and three CSS properties, so we won’t be going into details about them here.

Combining these variations (and more!)

Varying more than one of the above can help with interesting results.

By using top to bottom linear gradients for both the pattern and the map, with the pattern one having its size limited to10%of the element, we can get the effect below without needing to use amaskgradient with many irregulrly placed stops. Blending with some extra layers helps us with a nicer palette for the final result.

See Pure CSS retro wave by thebabydino on CodePen.

We can also animate a map’sbackground-positionto get a blinds effect like below:

See 1 div pure CSS blinds staggered animation in 13 declarations by thebabydino on CodePen.

In the demo above, we’ve also blended the halftone pattern with an image. Here’s another such example (note that this doesn’t work in Firefox due tobug 1481498, which has everything to do with the text on the right side and nothing to do with the halftone part):

card with halftone effect<br/>(live demo (<VPIcon icon="fa-brands fa-codepen"/>)) — card with halftone effect
(live demo (`thebabydino`))

Note that the code for all these demos so far is heavily commented, explaining the purpose of pretty much every CSS declaration in there.

The example below uses arepeating-radial-gradient() pattern and aconic-gradient() map, which funny enough, also creates a tiny heart in the middle.

See Heart in ripples pattern - 1 div, 5 CSS declarations by thebabydino on CodePen.

For a bit of a different effect, here’s a rhombic halftone one created by using two blended layers for the map - two otherwise identical linear gradients going in different directions:

See Varying stripes on rhombic tiling pattern by thebabydino on CodePen.

The demo below is a combination of two halftone patterns stacked one on top of the other, the top one being masked using aconic-gradient()checkerboardmask.

See 1 div, pure CSS halftone dash dot pattern by thebabydino on CodePen.

Here are a few more halftone samples as card backgrounds:

See #codeVember #22/2021: 1 div halftone patterns by thebabydino on CodePen.

Even more such halftone samples can be found in this gallery:

See Pure CSS 1 div card patterns (no SVG, no images other than CSS gradients) by thebabydino on CodePen.

We aren’t limited to 2D. We can also use such paterns in 3D and even animate them.

Finally, even more demos showcasing halftone patterns can be found inthis CodePen collection:

Pure CSS Halftone Effect in 3 Declarations
